Vixen AX103S Refractor ED Telescope Set
- AX103S ED apochromat with triplet ED objective
- Fully coated triplet ED objective
- Optimized for full-frame photography
- Build-in field flattener lens for sharp images
- Very high sharpness and contrast
The AX103S is a top-of-the-range ED apochromat in the refractor series. It features a triplet ED object lens and a rear-mounted field-flattener lens. The f8.0 refractor contains a central ED lens in the objective and reduces chromatic aberration to an absolute minimum.
An optional focal reducer can reduce the aperture ratio to 1:5.6 in order to provide quicker results for astrophotographers. The built-in field flattener lens provides a sharp image across the entire field of view – an essential requirement in astrophotography. The 60 mm ring on the focuser allows you to attach a 2’’ eyepiece and a camera adapter.
The AX103S is specially designed for photography, but also offers stunning visual performance, especially for observing the moon and the planets. The AX 103S is corrected for full-frame photography and provides razor-sharp pictures right into the corners of the image field.
This telescope is guaranteed to provide a lifetime of outstanding performance!
- Tube clamps and carry handle
- Illuminated 7x50 viewfinder telescope
- Folding mirror
|Optical design||Apochomatic Refractor|
|Mirror/Lens diam.||103 mm|
|Focal length and Aperture ratio||825 mm f/8.0|
|Angular resolution||1.13 arc seconds|
|Type of coating||Fully multi-coated|
|Color of coating||Green|
|Visual limiting magnitude||11.8 (approx., mag)|
|Dimensions||687mm x 115mm|
Vixen warranties its products to be free from initial defects in materials and workmanship for a specified period based on part type:
Vixen Electronic Parts: Limited One Year Warranty
Vixen Mechanical Parts: Limited Two Year Warranty
To download printable PDF manual Click Here
